Hydraulic Foaming Press — Specialty / Irregular Cabinets — CE / ISO 9001-certified linhas de produção by UREXCEED. Lead time 45 – 75 days, MOQ 1 set.
Hydraulic Foaming Press — Specialty / Irregular Cabinets
Standalone hydraulic foaming press for air-curtain, wine cabinet and irregular / non-standard cabinet foaming. Water-heated + air-cooling, 50 kW, 40–120 cabinets/shift. Complements existing line for capacity peaking.
Engineering reply within 24 hours
Quote + spec sheet + tailored sizing recommendation. WhatsApp answered 9 am–6 pm Beijing time.
Especificações
- Layout Form
- Hydraulic foaming press (standalone press for irregular / specialty cabinets)
- Drive Method
- Hydraulic
- Heating Method
- Water heating + air-cooling
- Number of Stations
- 1
- Cabinet Size Range (L×W×H)
- 4,000 × 1,800 × 550 mm
- Footprint (Overall L×W×H)
- Compact stand-alone (sized to floor space)
- Foaming Material
- POL + Cyclopentane + ISO / POL + HCFC-141a + ISO / POL + HCFC-245fa + ISO
- Voltage / Frequency
- 380V · 50 Hz · Control voltage 24V
- Total Power
- Approx. 50 kW
- Compressed Air Requirement
- 0.5 MPa
- Best Fit Capacity
- ~40 – 120 cabinets per shift
- Lead Time
- 45 – 75 days
- MOQ
- 1 set
Aplicações
- Air-curtain refrigerated cabinet specialty press (manual loading)
- Wine cabinet specialty press
- Irregular / non-standard cabinet foaming press
- Pre-press of insulation panels for thick-walled cabinets
- Standalone press complementing existing line (capacity peaking)
The hydraulic foaming press is a standalone press machine — not a production line. It clamps and foams ONE cabinet at a time, manually loaded. Use it for irregular / non-standard cabinets that a linear or rotary line can't accommodate: wine cabinets with deep cavities, cigar humidors with irregular geometry, air-curtain cabinets needing extra clamping force, or as a parallel station to peak line capacity.
When a standalone foaming press makes more sense than a line
Lines are designed for repetition — same cabinet type, same cycle, optimized throughput. The press is designed for variety — irregular cabinet geometries, one-off prototypes, capacity peaking for an existing line. Picking the press over a line saves 60–80% capex when your production is genuinely variant-heavy or volume-light.
Four reasons the press wins for irregular / specialty cabinet foaming
Engineering and economics of the standalone hydraulic press over a multi-station line.
Capex USD 90K–180K — line-level capex starts at USD 400K
Hydraulic press capex: USD 90K–180K turnkey for the full press unit + PU machine + control. Equivalent low-end line capex: USD 400K+ (8-station linear). For variant-heavy production, the press pays back through avoided line investment.
Handles cabinet envelope up to 4,000 × 1,800 × 550 mm — same as 4-station air-curtain
The press fixture accommodates long-format cabinets (wine cellar, supermarket service, panel pre-press) that standard production lines' single-station envelopes can't fit. Cabinet design freedom: irregular shapes, non-rectangular forms, thicker walls all supported.
Active heat + cool profile — supports thick-walled cabinet cure
Wine cabinet / cigar humidor cabinets need 70–90 mm thick walls for thermal performance. Standard lines cure 30–45 mm walls. The press water-heating + air-cooling profile supports 70–90 mm walls with 18–25 minute cycle (vs 8–12 min standard line).
Modular addition to existing line for peak capacity
If your main line is bottlenecked at 95% utilization and demand spikes, adding a press handles the overflow without expanding the line. Press throughput 40–120 cabinets/shift covers 10–30% capacity peaks for a typical 1,000-cabinet/day main line.
How the standalone foaming press cycle runs
Manual single-cabinet press cycle. ~3–5 minutes per cabinet depending on wall thickness and cabinet size.
- 1
Manual load — operator forklifts cabinet shell + inner liner onto press platform. Aligns reference marks. ~60–90 sec.
- 2
Hydraulic press close — press platen descends, clamps cabinet at 8–15 tons total force (varies by cabinet size). Verifies seal via PLC pressure sensor. ~15 sec.
- 3
PU injection — single-head pour delivers POL+ISO+cyclopentane sized to cabinet volume (2–6 kg). Mould-open injection style for irregular geometries. ~20 sec.
- 4
Heated cure + active cool — water-jacket heats to 48–58°C (varies by wall thickness). Cure 1–3 min for thin walls, 5–10 min for thick (wine cabinet). Air cool 30–60 sec.
- 5
Press release + demould — hydraulic press lifts, operator lifts cabinet onto outfeed cart. Spot-check density + warp before downstream. ~45 sec.
FAQs — hydraulic foaming press standalone
What's the price and lead time?
Capacity 40–120 cabinets/shift — for what factory volume?
Can this be the only foaming equipment in a new factory?
What cabinet thicknesses can it handle?
What end products does it foam?
How does this compare to a single-station specialty machine?
